当雨期或台风天气季来临场，有将发生洪水洪涝、狂风暴雨等必然洪涝的影响到，因柴油机打火机并网发电量厂冷水汽轮并网发电设备组计算机房平常是在半储藏室很有可能1楼易于被水淹，如果你并网发电量厂冷水汽轮并网发电设备组储放加固不当很有可能另一个因素水有将从烟管开启打火机缸体。当柴油机打火机并网发电量厂冷水汽轮并网发电设备组进水量的时，因在运行业务请直接暂停服务，并体现了用得着的保护，中断外主机电源及蓄电池组接驳线，同一检杳其他局部的进水量的情况下。

When the rainy season or typhoon season comes, it may be affected by natural disasters such as flood and rainstorm. Because the diesel generator set room is generally in the basement or the first floor, it is easy to be flooded. If the generator set is poorly kept and protected or for other reasons, water may enter the engine cylinder from the smoke pipe. When water enters the diesel generator set, if it is running, please shut down immediately, take necessary measures, disconnect the external power supply and battery connection line, and check the water inflow at all parts at the same time.

检查广西顶博发电机组制造进水常见问题

1、查检排气管管线（通风管更低处或消音器原理器）的排水的结构’有没滴水排出去。Check the exhaust pipe to see if there is water discharged from the drainage component.

2、捡查热空气机油滤清器设备壳能不能有雨水，滤心能不能被水浸渍。Check whether there is water in the air filter housing and whether the filter element is immersed in water.

3、诊断并网发三相电机壳体底能不有结水。Check whether there is water accumulated at the bottom of the generator casing.

4、观察热量散发器、排风扇、连轴器等转动结构件有没赌塞。Check radiator, fan, coupling for blockage.

5、间接能不充分油、然油或水的渗漏。Whether there is leakage of organic oil, fuel or water from the outside.

6、拆出来拐臂室盖，考察可否有入水。全面检查生产发三相电机绕阻绝缘层/废弃物实际情况。Remove the rocker chamber cover and observe whether there is water ingress. Check the insulation and ontamination of the generator windings.

7、检验的操作电缆线和伤害电路板的隔绝。检验的操作面板按钮开关组件、各仪表板、告警仪器、开启按钮开关。Check the insulation between the control circuit and the output circuit. Check the control panel module, each instrument, alarm device and start switch.

特别注意：一定不允许让水破坏汽车发驱动力的挥发室！Note: Never let water enter the combustion chamber of the engine!

漏液外理技巧重油发伺服电机柜机柜进行进水后的除理方式：Treatment  after water enter the generator:

当判定重油发电量厂工作设备发起机的丙烷冷却系统是没有渗水，绝缘性符合标准标准要求时，可起动重油发电量厂工作设备。在起动时要重视下例事情：When confirm there is no water in the combustion chamber  and the insulation meets the requirements,can start the generator. Pay attention to the following issues when starting:

1、在开始上升行几乎所有诊断，包含废气气油箱积水情况。电体统迅速上电，看是有不正常。Do all inspections before starting, including draining water in the fuel tank. The electrical system is gradually powered on, and observe whether there is any abnormality.

2、连续不断打火打着机的事件不恰突破57分钟钟。若打着机不许失火，则定期检查燃料管线及电器回路开关，两三7分钟后又一次打火。Start the engine continuously shall not exceed 30 seconds. If the engine cannot catch fire, check the fuel line and electrical circuit, and start again after one or two minutes.

3、查验汽车发驱动力声需不需要有不正常，需不需要有有味道。查验高压电器仪器的表明、液晶板表明屏需不需要断屏还是表明不清。

Check whether the engine sound is abnormal and whether there is a peculiar smell. Check whether the display of the electrical instrument and the LCD screen are broken or unclear.

4、关系密切捡查润滑油经济压力和水水温因素，但如果汽压或水温因素不一致合技術规范了，应取消打着机。停用后，捡查以此润滑油剖面。Closely observe the oil pressure and water temperature. If the oil pressure or temperature does not meet the technical specifications, the engine should be shut down. After stopping, check the oil level.

当辨别起驱动力或者水进、火力发交流接触器绝缘性一致合需要时，以免擅自改变处理，应开拓市场火力发交流接触器组生产厂家的专业技术职称工艺考生的促进。When it is judged that water may enter the engine and the insulation of the generator does not meet the requirements, do not repair it without authorization, and seek the help of professional technicians from the generator manufacturer.

强降雨/朝湿区域，柴油密度并网发发电冷水机组便用重视基本原则Key points for unit operation in rainstorm / humid environment

1、储放生态规定要求1. Placement environment requirements（1）室内放到动用的超临界锅炉，需干好防水布处理，配资防水布棚、禁音箱等；

Rainproof measures shall be taken for units placed outdoors, and rainproof sheds, static speakers, etc. shall be equipped;

（2）汽轮火力发主轴电机组壳体须有安全的确保接地系统保护系统，对要有有碱式盐点立即接地系统保护系统的火力发主轴电机,则一定由专业工作人员展开碱式盐接地系统保护系统；The shell of the unit must be reliably grounded. For generators requiring direct neutral grounding, the neutral grounding must be carried out by professionals;

（3）打雷闪电多见中南部操作机器设备，请调试防雷装制。If machines are used in lightning prone areas, please configure lightning protection devices.

（4）请要将工作机组放到于地形地貌较低，基础桩不牢（淤泥室内地面）可能积水情况的空间；Please do not place the unit in a place with low terrain, weak foundation (soil ground) and easy to accumulate water;

（5）码放在地面下层室用到的产品，需做到位地面下层室排水管道、防潮办公。For machines placed in the basement, drainage and moisture-proof work in the basement shall be done well.
